LSR400 Flexible low loss coaxial cable specifications
Description:
. Conductor:BC(Bare Copper)
. Insulation Material: Foam PE
.1st Shielding: Aluminum Tape
.2nd Shielding: Tinned Copper Braiding
. Impedance:50Ω±2
.Jacket: PE, PVC, LSZH
. Color: Black,White
Typical Application:
1.LSR400 is the same specification as LMR 400, generally designed for jumper assemblies in wireless communications systems
2.LSR400 can replace for RG8 air-dielectric type cable.
3. LSR400 has PE jacket, PVC jacket, LSZH jacket Flame-retardant LSZH jacket, Flame-retardant PVC jacket for different environment
Best Feature:
1. LSR400/ LMR 400 cable features a flexible outer conductor, allowing the tightest bend radius of any cable of similar size and performance.
2.Low Loss: Lowest loss of any flexible cable; comparable loss to semi–rigid cables
3. AL/PET Tape (Aluminum Mylar Tape) is used for cable shielding as a shielding insulator when assembling electronic components. AL/PET Tapes provide more protection by increasing the metallic coverage without adding increased thickness to the diameter of the cable. It comes in 3 different colors: Dark Blue, Light Blue, and Silver
Please contact us for LSR400 cable assembly with N connector to SMA connector
